BOMAG

CR 452

Asphalt Paver

Paving Width - max
336 in
Gross Power
164.0 hp
Length w/ Screed
120 in
All asphalt pavers
BOMAG CR 452 Asphalt Paver
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

44 data points

Operating Specifications

Operating Specifications specifications
Operating Weight38,495 lb
Fuel Capacity72.0 gal
Hydraulic System Fluid Capacity75.0 gal
Operating Voltage12 V
Cooling System Fluid Capacity6.5 gal

Engine

Engine specifications
Engine ModelQSB6.7
Power Measured @2,200 rpm
Gross Power164.0 hp
AspirationTurbocharged
Engine MakeCummins
MakeCummins
Emission Tier LevelTier 4i

Weights

Weights specifications
Tractor Weight30,596 lb
Tractor Weight - with Fastach 8 and hydroflated tires34,595 lb
Tractor Weight - with Stretch 16 and hydroflated tires38,495 lb

Dimensions

Dimensions specifications
Overall Length445 in
Transport Width72 in
Transport Height104 in
Track Width36 in
Length w/ Screed120 in

Brakes & Steering

Brakes & Steering specifications
Parking brakeMultiple disc

Tires & Wheels

Tires & Wheels specifications
Drive Tires25.00 in (63.50 cm)
Front Wheels22 in

Hopper/Paver

Hopper/Paver specifications
Paving Width - max336 in
Paving Speed - max3.5 mph
Hopper Capacity25,400 lb
Travel Speed - max10.0 mph
Auger Diameter16 in
Hopper Length71 in
Auger ConstructionCast High alloy
Auger Thickness1 in
Feed Tunnel Width25 in
Hopper Volume8.20 yd³
Hopper Width119 in
Paving Depth - max12 in
Slat Conveyor Liner Thickness0 in

Screed

Screed specifications
Fastach 8 (electric heat) generator45.6 hp
Fastach 8 (two oil heaters) 178,000 BTU1.3 gph
Negative crown1 in
Positive crown3 in
Screed plate thickness1 in
Stretch 16 (four oil heaters) 274,000 BTU (total)2.0 gph
Stretchà ® 16 (electric heat) generator45.6 hp
Vibrations per minute (max)3,000
