BT
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 7,165 lb |
|---|---|
| Max Speed | 11.2 mph |
| Number of Front Wheels | 2 – 4 |
| Number of Rear Wheels | 2 |
| Tire Type | front 23x9-10 rear 18x7-8 |
Engine
| Engine Model | 1 DZ-II |
|---|---|
| Displacement | 152 in³ |
| Power Measured @ | 1,800 rpm |
| Power | 53.7 hp |
| Fuel Type | diesel |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 59 in |
| Overall Width | 44 in |
| Turning Radius | 81 in |
| Overall Height - mast lowered | 81 in |
| Length to Fork Face | 90 in |
| Height to Top of Overhead Guard | 84 in |
| Max Fork Height | 118 in |
Mast
| Load Capacity | 3,968 lb |
|---|---|
| Load Center | 20 in |
| Lift Speed | 1.2 mph |
| Mast Tip Forward | 5 ° |
| Mast Tip Rear | 10 ° |
| Lower Speed | 1.2 mph |
