Carelift
Hyster
H110FT
Forklift
38 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 24,251 lb |
|---|---|
| Fuel Capacity | 41.0 gal |
| Tire Size | 14.00 x 24 - 12 ply |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 A |
Engine
| Engine Model | QSB 4.5 |
|---|---|
| Power Measured @ | 2,500 rpm |
| Gross Power | 110.0 hp |
| Engine Make | Cummins |
Hydraulic System
| Pump Flow Capacity | 36.0 gal/min |
|---|
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 120 in |
| Overall Height | 95 in |
| Length to Fork Face | 240 in |
| Width | 101 in |
| Turning Radius Outside Tires | 142 in |
Transmission
| Max Speed - Forward | 21.8 mph |
|---|---|
| Transmission Type | Electronic powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
Lift System
| Max Lift Height | 528 in |
|---|---|
| Max Forward Reach | 359 in |
