Case IH
Fendt
817
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 17,589 lb |
|---|---|
| Fuel Capacity | 85.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 7,749 lb |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 33.3 gal |
Engine
| Displacement | 507 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Number of Cylinders | 6 |
| Engine Make | CaseIH |
| PTO Power | 182.0 hp |
| Bore | 5 in |
| Stroke | 5 in |
Hydraulic System
| Pump Flow Capacity | 30.0 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Pump Type | Closed center |
| Maximum system pressure | 2,250 psi |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 117 in |
| Overall Length | 192 in |
| Overall Width | 60 in |
| Height - Top of ROPS/FOPS | 120 in |
Transmission
| Number of Forward Gears | 24 |
|---|---|
| Transmission Type | Partial power shift |
| Number of Reverse Gears | 3 |
