Case IH
MX245
- Operating Weight
- 21,184 lb
- Displacement
- 507 in³
- Power Measured @
- 2,000 rpm
- Gross Power
- 248.0 hp
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 21,184 lb |
|---|---|
| Fuel Capacity | 180.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 13,960 lb |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 45.5 gal |
Engine
| Displacement | 507 in³ |
|---|---|
| Power Measured @ | 2,000 rpm |
| Gross Power | 248.0 hp |
| Net Power | 200.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,616 lb-ft |
| Engine Make | CaseIH |
| Stroke | 5 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 38.6 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Pump Type | Pressure flow compensating |
Dimensions
| Wheelbase | 119 in |
|---|---|
| Height - Top of ROPS/FOPS | 128 in |
Transmission
| Number of Forward Gears | 18 |
|---|---|
| Transmission Type | Full power shift |
| Number of Reverse Gears | 4 |
Production
| Series | Magnum Series |
|---|---|
| Years Manufactured | 2,006 – 2,007 |
