Mccormick

MC120 Power6

Tractor

Operating Weight
12,853 lb
Displacement
366 in³
Power Measured @
2,200 rpm
Gross Power
115.0 hp
All tractors
Mccormick MC120 Power6 Tractor
1 / 5
Image 1 of 5
Image: tractordata.site

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight12,853 lb
Fuel Capacity70.1 gal
3 Point Hitch Lift Capacity @ 24 inches12,943 lb
3 Point Hitch TypeCat IIIN
Turning Radius190 in
Alternator Supplied Amperage95 A

Engine

Engine specifications
Displacement366 in³
Power Measured @2,200 rpm
Gross Power115.0 hp
Number of Cylinders6
Aspirationturbocharged wastegate intercooler
Torque Rise24.0 %

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity28.8 gal/min

Dimensions

Dimensions specifications
Height - Top of Cab111 in
Wheelbase104 in
Overall Length16 in
Tire Sizefront 14.9/28 rear 18.4/38
Width Outside Frame91 in

Transmission

Transmission specifications
Max Speed23.4 mph
Number of Forward Gears16
Number of Reverse Gears12
