Case IH
PUMA 180
- Operating Weight
- 20,944 lb
- Displacement
- 409 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 179.7 hp
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 20,944 lb |
|---|---|
| Fuel Capacity | 108.4 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 19,063 lb |
Engine
| Displacement | 409 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 179.7 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 623 lb-ft |
| Stroke | 5 in |
| Bore | 4 in |
Hydraulic System
| Pump Flow Capacity | 31.8 gal/min |
|---|---|
| Number of Remote Control Valves | 4 |
| Maximum system pressure | 3,118 psi |
Dimensions
| Wheelbase | 114 in |
|---|---|
| Overall Length | 194 in |
| Overall Width | 106 in |
| Height - Top of ROPS/FOPS | 120 in |
Production
| Series | Puma Series |
|---|---|
| Years Manufactured | 2,007 – 2,010 |
