Case IH
PUMA 200
- Operating Weight
- 15,920 lb
- Displacement
- 409 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 200.0 hp
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 15,920 lb |
|---|---|
| Fuel Capacity | 104.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 10,274 lb |
| Alternator Supplied Amperage | 150 A |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 22.0 gal |
| Engine Oil Capacity | 16.0 gal |
Engine
| Displacement | 409 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 200.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Cross-Flow Aspiration / Turbocharged |
| PTO Power | 165.0 hp |
Hydraulic System
| Pump Flow Capacity | 30.0 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
| Pump Type | Closed Center Pressure Flow Compensating |
Dimensions
| Wheelbase | 114 in |
|---|
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 18 |
| Number of Reverse Gears | 6 |
Production
| Series | Puma Series |
|---|---|
| Years Manufactured | — |
