Case
New Holland
D150
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 36,691 lb |
|---|---|
| Fuel Capacity | 65.0 gal |
| Cooling System Fluid Capacity | 34.0 gal |
| Final Drives Fluid Capacity | 15.0 gal |
| Engine Oil Capacity | 16.5 gal |
| Hydraulic Fluid Capacity | 26.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 65 A |
Engine
| Engine Model | 667TA/EDJ |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 156.0 hp |
| Net Power | 144.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 509 lb-ft |
| Make | Case |
Hydraulic System
| Pump Flow Capacity | 34.9 gal/min |
|---|---|
| Relief Valve Pressure | 2,830 psi |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 121 in |
| Width Over Tracks | 134 in |
| Length w/ Blade | 223 in |
Transmission
| Max Speed - Forward | 6.0 mph |
|---|---|
| Max Speed - Reverse | 6.0 mph |
| Transmission Type | Hydrostatic |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 84 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 45 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 28 in |
| Ground Contact Area | 6,721 in³ |
| Track Pitch | 8 in |
Standard Blade
| Width | 95 in |
|---|---|
| Height | 39 in |
| Capacity | 4.20 yd³ |
| Blade Angle (both directions) | 25 ° |
