Case
521G
- Operating Weight
- 24,291 lb
- Bucket Capacity - heaped
- 2.39 yd³
- Gross Power
- 142.0 hp
- Net Power
- 129.0 hp
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight | 24,291 lb |
|---|---|
| Fuel Capacity | 50.0 gal |
| Operating Voltage | 24 V |
| Rear Axle Oscillation | 24 ° |
| Front Axle/Diff Fluid Capacity | 5.9 gal |
| Rear Axle/Diff Fluid Capacity | 5.9 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Transmission Fluid Capacity | 6.9 gal |
| Rated Bucket Capacity | 2.30 yd³ |
| DEF tank capacity | 11.7 gal |
Engine
| Engine Model | FPT F4HFE413NB |
|---|---|
| Displacement | 275 in³ |
| Gross Power | 142.0 hp |
| Net Power | 129.0 hp |
| Number of Cylinders | 4 |
| Max Torque | 448 lb-ft |
| Make | Case |
| Torque Rise | 21.0 % |
| Alternator | 70 A |
| Rated Engine Speed | 2,000 rpm |
| Emissions | Tier 4 |
Weights
| Operating Weight | 24,203 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 35.4 gal/min |
|---|---|
| Pump Type | Piston |
| Steering pump type | Articulation |
| Maximum system pressure | 3,625 psi |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 130 in |
| Wheelbase | 109 in |
| Width Over Tires | 97 in |
| Reach at Max Lift and Dump | 57 in |
| Hinge Pin - Max Height | 143 in |
| Overall length (L/bucket) | 264 in |
| Turning Radius Outside Tires | 198 in |
| Dump height - fully raised, 45 degrees dump | 107 in |
| Overall width without bucket | 96 in |
| Bucket reach - fully raised, 45à ° dump | 40 in |
| Operating height - fully raised with spillgaurd | 184 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Differential lock | F: LSD / R: LSD |
Brakes & Steering
| Service brake | Wet Multi Disc |
|---|
Bucket
| Bucket Capacity - heaped | 2.39 yd³ |
|---|---|
| Dump Clearance at Max Raise | 102 in |
| Breakout Force | 19,356 lb |
General Specifications
| Operating Weight | 24,203 (10,978) Starting 2019 Model Year |
|---|---|
| Bucket Capacity | 2.1 (1.6) Starting 2024 Model Year |
| Engine type | Case/FPT Starting 2019 Model Year |
| Engine Power | 131 (98) Starting 2019 Model Year |
| Max Dump Height | 9.1 (2.8) Starting 2024 Model Year |
Hydraulic cycle times (unloaded)
| Total cycle time | 10.5 s |
|---|
Performance
| Tipping Load | 17,683 lb |
|---|
