434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight 4wd | 13,283 lb |
|---|---|
| Fuel Capacity | 31.4 gal |
| Hydraulic System Fluid Capacity | 33.0 gal |
| Cooling System Fluid Capacity | 4.4 gal |
| Tire Size Front - 2wd / 4wd | 11L x 16 10PR / 12 x 16.5 8PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
| Transmission Fluid Capacity | 4.9 gal |
| Rear Axle Fluid Capacity | 3.8 gal |
| Front Axle Fluid Capacity | 1.5 gal |
Engine
| Engine Model | 4T-390 |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 91.0 hp |
| Net Power | 86.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Engine Make | Case |
| Bore | 4 in |
| Stroke | 5 in |
| Net Max Torque | 252 lb-ft |
Hydraulic System
| Pump Flow Capacity | 27.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,500 psi |
| Pump Type | Front mounted positive displacement gear-type tandem |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 86 in |
| Transport Length | 272 in |
| Height to Top of Suspended Cab | 97 in |
| Front Wheel Tread Width | 68 in |
| Rear Wheel Tread Width - min | 61 in |
Transmission
| Max Speed | 25.8 mph |
|---|---|
| Max Speed - Reverse | 31.1 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Fully synchronized 4-speed forward reverse shuttle |
Tires & Wheels
| Rear Tires Size | 17.5L x 24 10PR / 19.5L x 24 10PR |
|---|
Backhoe
| Dig Depth | 174 in |
|---|---|
| Reach From Swivel | 217 in |
| Dig Depth - Extended | 220 in |
| Load Height - Extended | 159 in |
| Bucket Dig Force | 13,126 lb |
| Reach From Swivel - Extended | 253 in |
| Reach at Load Height - Extended | 139 in |
| Bucket Dig Force - Extended | 13,126 lb |
Loader
| Bucket Capacity | 1.10 yd³ |
|---|---|
| Clearance at Max Dump Height | 97 in |
| Bucket Breakout Force | 9,667 lb |
| Bucket Width | 82 in |
| Reach at Max Dump Height | 29 in |
| Dig Depth | 6 in |
