Case
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Fuel Capacity | 33.3 gal |
|---|---|
| Hydraulic System Fluid Capacity | 31.2 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Tire Size Front - 2wd / 4wd | 18 inches /20 inches |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.6 gal |
| Alternator Supplied Amperage | 120 A |
| Turning Radius | 170 in |
| Transmission Fluid Capacity | 4.9 gal |
| Max Weight | 19,103 lb |
| Rear Axle Fluid Capacity | 4.4 gal |
Engine
| Engine Model | 445TA/ML5 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 97.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,400 rpm |
| Engine Make | FPT NEF4 |
| Bore | 4 in |
| Stroke | 5 in |
| Net Max Torque | 334 lb-ft |
Hydraulic System
| Pump Flow Capacity | 41.3 gal/min |
|---|---|
| Relief Valve Pressure | 2,973 psi |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 86 in |
| Transport Width | 96 in |
| Height to Top of Suspended Cab | 117 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Max Speed - Reverse | 29.3 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Powershuttle |
Tires & Wheels
| Rear Tires Size | 28 inches /30 inches |
|---|
Backhoe
| Dig Depth | 175 in |
|---|---|
| Reach From Swivel | 223 in |
| Dig Depth - Extended | 222 in |
| Reach From Swivel - Extended | 250 in |
Loader
| Clearance at Max Dump Height | 107 in |
|---|---|
| Bucket Breakout Force | 913,174 lb |
| Reach at Max Dump Height | 33 in |
| Dig Depth | 5 in |
