Case
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
56 data points
Operating Specifications
| Operating Weight 4wd | 15,414 lb |
|---|---|
| Operating Weight 2wd | 15,128 lb |
| Fuel Capacity | 31.4 gal |
| Hydraulic System Fluid Capacity | 33.0 gal |
| Cooling System Fluid Capacity | 4.4 gal |
| Tire Size Front - 2wd / 4wd | 14.5/.75 x 16.1 10PR / 14 x 17.5 10PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.9 gal |
| Alternator Supplied Amperage | 65 A |
| Transmission Fluid Capacity | 4.9 gal |
| Rear Axle Fluid Capacity | 3.0 gal |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4T-390 |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 95.0 hp |
| Net Power | 88.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Engine Make | Case |
| Bore | 4 in |
| Stroke | 5 in |
| Net Max Torque | 260 lb-ft |
Hydraulic System
| Pump Flow Capacity | 30.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Front mounted positive displacement gear-type tandem |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 94 in |
| Transport Length | 283 in |
| Height to Top of Suspended Cab | 98 in |
| Front Wheel Tread Width | 69 in |
| Rear Wheel Tread Width - min | 64 in |
Transmission
| Max Speed | 26.3 mph |
|---|---|
| Max Speed - Reverse | 31.6 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Fully synchronized 4-speed forward reverse shuttle |
Tires & Wheels
| Rear Tires Size | 21L x 24 10PR |
|---|
Backhoe
| Dig Depth | 189 in |
|---|---|
| Reach From Swivel | 238 in |
| Dig Depth - Extended | 236 in |
| Load Height - Extended | 169 in |
| Bucket Dig Force | 13,126 lb |
| Reach From Swivel - Extended | 284 in |
| Reach at Load Height - Extended | 146 in |
| Load Height | 138 in |
| Bucket Dig Force - Extended | 13,126 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Lift Capacity | 3,430 lb |
| Clearance at Max Dump Height | 108 in |
| Bucket Breakout Force | 8,900 lb |
| Bucket Width | 93 in |
| Reach at Max Dump Height | 26 in |
| Dig Depth | 4 in |
