Case
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
51 data points
Operating Specifications
| Operating Weight 4wd | 15,269 lb |
|---|---|
| Fuel Capacity | 42.1 gal |
| Hydraulic System Fluid Capacity | 33.8 gal |
| Cooling System Fluid Capacity | 4.8 gal |
| Tire Size Front - 2wd / 4wd | 14.5/75x16.1 10ply / 14x17.5 10 ply |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.6 gal |
| Alternator Supplied Amperage | 90 A |
| Turning Radius | 149 in |
| Transmission Fluid Capacity | 5.2 gal |
| Max Weight | 19,579 lb |
| Rear Axle Fluid Capacity | 5.0 gal |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | Family IV 445TA/E3 diesel Tier III certified |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 110.0 hp |
| Net Power | 108.7 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Net Max Torque | 372 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 42.6 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Piston variable displacement |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 85 in |
| Transport Width | 94 in |
| Transport Length | 283 in |
| Height to Top of Suspended Cab | 107 in |
Transmission
| Max Speed | 25.6 mph |
|---|---|
| Max Speed - Reverse | 30.7 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | synchromesh |
Tires & Wheels
| Rear Tires Size | 21Lx24 10 ply / 21Lx24 10ply |
|---|
Backhoe
| Dig Depth | 192 in |
|---|---|
| Reach From Swivel | 236 in |
| Dig Depth - Extended | 240 in |
| Load Height - Extended | 166 in |
| Bucket Dig Force | 14,718 lb |
| Reach From Swivel - Extended | 283 in |
| Reach at Load Height - Extended | 154 in |
| Bucket Dig Force - Extended | 14,718 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 109 in |
| Bucket Breakout Force | 10,729 lb |
| Bucket Width | 93 in |
| Reach at Max Dump Height | 28 in |
| Dig Depth | 4 in |
