Case
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 16,244 lb |
|---|---|
| Long track | 15,803 lb |
| Low ground pressure | 16,839 lb |
| Winch | 1,861 lb |
| Sweeps | 110 lb |
| center rock guard | 157 lb |
Engine
| Engine Model | FPT F5HFL463D G003 |
|---|---|
| Displacement | 208 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 73.8 hp |
| Net Power | 68.0 hp |
| Number of Cylinders | 4 |
| Emission Tier Level | Tier 4 |
| Cooling system | 23.9 Qt(22.6 Lt rs) |
| Fuel tank | 40.8 gal |
| Transmission Type | Hydrostatic |
| Pump operating angles - Fore and aft | 45 ° |
| Pump operating angles -Side-to-side | 35 ° |
| Fan | 20 in(500m)DiameterRatio-1:1:1 |
Weights
| Ripper weight | 1,400 lb |
|---|---|
| Counterweight | 838 lb |
| Cab | 1,874 lb |
Hydraulic System
| Pump Flow Capacity | 20.9 gal/min |
|---|---|
| Lift cylinder - Rod diameter | 2 in |
| Lift cylinder - Stroke | 16 in |
| Lift cylinder(s) | 2 |
| Lift cylinder-Bore diameter | 4 in |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 104 in |
| Length of Track on Ground | 1,020 in |
| Blade depth below ground | 21 in |
| Blade lift above ground | 35 in |
Transmission
| Max Speed - Forward | 5.0 mph |
|---|---|
| Max Speed - Reverse | 5.0 mph |
Undercarriage
| Number of Shoes per Side | 40 |
|---|---|
| Number of Upper Rollers | 1 |
| Width of Shoes | 1 in |
| Number of bottom rollers per side | 6 |
Fluid Capacities
| Engine oil with filter | 3.3 gal |
|---|
Drive System
| Final drive | 2 helical gear |
|---|---|
| Max drawbar pull | 39,094 lb |
| Parking brakes | Heavy-duty spring-applied |
Blades
| Blade Width | 120 in |
|---|---|
| Blade Height | 33 in |
| Blade Capacity | 2.20 yd³ |
| Blade Type | PAT |
Standard Blade
| Blade Angle (both directions) | 27 ° |
|---|
Electrical System
| Alternator | — |
|---|---|
| Battery | 12-volt low-maintenance |
Performance
| Pump Flow | 20.3 gal/min |
|---|
