Case

680K

Backhoe Loader

Max Speed
19.4 mph
Gross Power
101.0 hp
Net Power
90.0 hp
All backhoe loaders
Case 680K Backhoe Loader
1 / 5
Image 1 of 5
Image: brokentractor.com

Specifications

42 data points

Operating Specifications

Operating Specifications specifications
Hydraulic System Fluid Capacity13.7 gal
Cooling System Fluid Capacity6.8 gal
Tire Size Front - 2wd / 4wd12.5Lx16
Operating Voltage12 V
Oil System Fluid Capacity3.1 gal
Alternator Supplied Amperage40 A
Max Weight14,900 lb

Engine

Engine specifications
Displacement360 in³
Power Measured @2,200 rpm
Gross Power101.0 hp
Net Power90.0 hp
Torque Measured @1,200 rpm
Engine MakeJ.I. Case
Stroke5 in
Bore4 in
Net Max Torque260 lb-ft

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity44.4 gal/min
Relief Valve Pressure2,000 psi

Dimensions

Dimensions specifications
Wheelbase88 in
Transport Width91 in
Transport Length276 in
Height to Top of Suspended Cab115 in
Rear Tread Range67 in
Front Wheel Tread Width72 in

Transmission

Transmission specifications
Max Speed19.4 mph
Max Speed - Reverse19.4 mph
Number of Forward Gears3
Number of Reverse Gears3
Transmission TypePower shift

Tires & Wheels

Tires & Wheels specifications
Rear Tires Size16.9x24

Backhoe

Backhoe specifications
Dig Depth198 in
Reach From Swivel238 in
Dig Depth - Extended260 in
Load Height - Extended168 in
Bucket Dig Force11,289 lb
Reach From Swivel - Extended288 in
Load Height134 in
Bucket Dig Force - Extended11,812 lb

Loader

Loader specifications
Clearance at Max Dump Height114 in
Bucket Breakout Force10,020 lb
Bucket Width86 in
Reach at Max Dump Height31 in
