Case
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
Case
721B
- Operating Weight
- 29,763 lb
- Bucket Capacity - heaped
- 2.80 yd³
- Gross Power
- 151.6 hp
- Net Power
- 136.6 hp
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 29,763 lb |
|---|---|
| Fuel Capacity | 53.9 gal |
| Hydraulic System Fluid Capacity | 40.5 gal |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 5.6 gal |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 4.0 gal |
| Rear Axle/Diff Fluid Capacity | 2.6 gal |
Engine
| Engine Model | 6T-830 |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 151.6 hp |
| Net Power | 136.6 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Stroke | 5 in |
| Bore | 5 in |
| Engine Type | 4 stroke Direct injection |
| Max torque ISO TR14396 | 458 lb-ft |
Hydraulic System
| Pump Flow Capacity | 57.6 gal/min |
|---|---|
| Raise Time | 5.9 s |
| Lower Time | 4.6 s |
| Dump Time | 1.8 s |
| Pump Type | Hydraulic tandem pump |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 115 in |
| Width Over Tires | 96 in |
| Length with Bucket on Ground | 275 in |
| Hinge Pin - Max Height | 146 in |
Transmission
| Max Speed - Forward | 22.2 mph |
|---|---|
| Max Speed - Reverse | 14.2 mph |
| Transmission Type | Mechanical |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.80 yd³ |
|---|---|
| Bucket Capacity - struck | 2.39 yd³ |
| Breakout Force | 27,629 lb |
| Bucket Width | 100 in |
