Case
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 16,089 lb |
|---|---|
| Fuel Capacity | 40.0 gal |
| Cooling System Fluid Capacity | 5.0 gal |
| Final Drives Fluid Capacity | 1.9 gal |
| Engine Oil Capacity | 4.1 gal |
| Hydraulic Fluid Capacity | 12.1 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | 6-590/6T-590 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 90.0 hp |
| Net Power | 82.0 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 253 lb-ft |
Dimensions
| Height - Top of Cab | 107 in |
|---|---|
| Length w/ Blade | 158 in |
Transmission
| Max Speed - Forward | 6.3 mph |
|---|---|
| Max Speed - Reverse | 6.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Undercarriage
| Ground Pressure | 28 psi |
|---|---|
| Track Gauge | 71 in |
| Number of Track Rollers per Side | 5 |
| Number of Shoes per Side | 38 |
| Number of Carrier Rollers per Side | 1 |
| Standard Shoe Size | 29 in |
