Case
New Holland
E265EL
Excavator
58 specifications
1 / 5
Image 1 of 5
Specifications
61 data points
Operating Specifications
| Operating Weight | 99,950 lb |
|---|---|
| Fuel Capacity | 172.0 gal |
| Hydraulic Pump Flow Capacity | 89.9 gal/min |
| Hydraulic System Fluid Capacity | 118.9 gal |
| Hydraulic System Relief Valve Pressure | 4,620 psi |
| Engine Oil Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 15.9 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 5.6 gal |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | M11-C320 |
|---|---|
| Displacement | 661 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 300.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 958 lb-ft |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 131 in |
| Length of Track on Ground | 168 in |
| Tail Swing Radius | 143 in |
| Width to Outside of Tracks | 144 in |
| Removal Counterweight Clearance | 55 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.1 mph |
| Shoe Size | 35 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 71,000 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 386 in |
|---|---|
| Max Reach Along Ground | 535 in |
| Max Loading Height | 331 in |
| Max Vertical Wall Digging Depth | 331 in |
| Max Cutting Height | 461 in |
| Shipping Length of Unit | 465 in |
| Shipping Height of Unit | 194 in |
Bucket
| Reference Bucket Capacity | 2.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 3.30 yd³ |
| Minimum Bucket Capacity | 1.70 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 331 in |
|---|---|
| Max Vertical Wall Digging Depth | 275 in |
| Max Cutting Height | 443 in |
| Max Loading Height | 313 in |
| Max Reach Along Ground | 483 in |
| Shipping Length of Unit | 473 in |
| Shipping Height of Unit | 142 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 306 in |
|---|---|
| Max Cutting Height | 435 in |
| Max Loading Height | 307 in |
| Max Vertical Wall Digging Depth | 251 in |
| Max Reach Along Ground | 462 in |
| Shipping Length of Unit | 472 in |
| Shipping Height of Unit | 138 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 272 in |
|---|---|
| Max Cutting Height | 426 in |
| Max Reach Along Ground | 432 in |
| Max Loading Height | 298 in |
| Max Vertical Wall Dig Depth | 219 in |
| Shipping Length of Unit | 473 in |
