John Deere
792D LC
- Operating Weight
- 60,250 lb
- Max Digging Depth
- 285 in
- Max Digging Depth
- 335 in
- Net Power
- 165.0 hp
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 60,250 lb |
|---|---|
| Fuel Capacity | 82.0 gal |
| Hydraulic Pump Flow Capacity | 138.4 gal/min |
| Hydraulic System Fluid Capacity | 79.0 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 25.4 gal |
| Cooling System Fluid Capacity | 30.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 10.0 gal |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | 6076A |
|---|---|
| Displacement | 466 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 173.0 hp |
| Net Power | 165.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,350 rpm |
| Max Torque | 604 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 158 in |
| Tail Swing Radius | 120 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 2.9 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 44,000 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 285 in |
|---|---|
| Max Reach Along Ground | 414 in |
| Max Loading Height | 276 in |
| Max Vertical Wall Digging Depth | 240 in |
| Max Cutting Height | 390 in |
| Shipping Length of Unit | 411 in |
| Shipping Height of Unit | 126 in |
Bucket
| Reference Bucket Capacity | 1.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.11 yd³ |
| Minimum Bucket Capacity | 0.99 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 335 in |
|---|---|
| Max Vertical Wall Digging Depth | 265 in |
| Max Cutting Height | 401 in |
| Max Loading Height | 289 in |
| Max Reach Along Ground | 439 in |
| Shipping Length of Unit | 414 in |
| Shipping Height of Unit | 128 in |
