Case
Hitachi
EX135USR
Excavator
23 specifications
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Operating Weight | 29,101 lb |
|---|---|
| Fuel Capacity | 68.7 gal |
| Hydraulic Pump Flow Capacity | 68.2 gal/min |
| Hydraulic System Fluid Capacity | 41.5 gal |
| Cooling System Fluid Capacity | 4.3 gal |
Engine
| Engine Model | AM-4JJ1X |
|---|---|
| Power Measured @ | 2,000 rpm |
| Net Power | 100.5 hp |
| Aspiration | Turbocharger |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 265 lb-ft |
| Engine Make | Isuzu |
| Stroke | 4 in |
| Bore | 4 in |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 115 in |
| Length of Track on Ground | 149 in |
| Tail Swing Radius | 84 in |
| Width to Outside of Tracks | 102 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 47 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 26,078 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 219 in |
|---|---|
| Max Reach Along Ground | 328 in |
| Max Loading Height | 252 in |
| Max Vertical Wall Digging Depth | 323 in |
| Max Cutting Height | 346 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 115 in |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 239 in |
|---|---|
| Max Vertical Wall Digging Depth | 341 in |
| Max Cutting Height | 356 in |
| Max Loading Height | 264 in |
| Max Reach Along Ground | 346 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 115 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 203 in |
|---|---|
| Max Cutting Height | 337 in |
| Max Loading Height | 244 in |
| Max Vertical Wall Digging Depth | 308 in |
| Max Reach Along Ground | 315 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 115 in |
