Case
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 3,748 lb |
|---|---|
| Fuel Capacity | 5.2 gal |
| Hydraulic Pump Flow Capacity | 4.1 gal/min |
| Hydraulic System Fluid Capacity | 3.3 gal |
| Hydraulic System Relief Valve Pressure | 2,988 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 0.8 gal |
| Cooling System Fluid Capacity | 1.0 gal |
Engine
| Engine Model | L3E |
|---|---|
| Displacement | 58 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 15.0 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 39 lb-ft |
Dimensions
| Height - Top of Cab | 94 in |
|---|---|
| Length of Track on Ground | 48 in |
| Tail Swing Radius | 42 in |
| Width to Outside of Tracks | 40 in |
| Removal Counterweight Clearance | 18 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 30 in |
| Number of Track Rollers per Side | 3 |
| Max Travel Speed | 2.2 mph |
| Shoe Size | 9 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 88 in |
|---|---|
| Max Reach Along Ground | 146 in |
| Max Vertical Wall Digging Depth | 81 in |
| Max Loading Height | 98 in |
| Shipping Length of Unit | 143 in |
| Max Cutting Height | 141 in |
| Shipping Height of Unit | 94 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 95 in |
|---|---|
| Max Cutting Height | 145 in |
| Max Loading Height | 103 in |
| Max Vertical Wall Digging Depth | 90 in |
| Max Reach Along Ground | 154 in |
| Shipping Height of Unit | 94 in |
| Shipping Length of Unit | 143 in |
