Case
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
59 data points
Operating Specifications
| Operating Weight | 3,913 lb |
|---|
Engine
| Engine Model | Kubota D902 |
|---|---|
| Displacement | 55 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 16.8 hp |
| Net Power | 15.8 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,900 rpm |
| Max Torque | 39 lb-ft |
| Cooling system | Water-cooled |
| Fuel | Diesel |
| Emissions level | Tier 4 Final |
| Fuel injection | Mechanical |
| Max speed | 2.6 mph |
Hydraulic System
| Main pump - Maximum flow | — |
|---|---|
| Relief Pressure | — |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 93 in |
| Length of Track on Ground | 64 in |
| Tail Swing Radius | 26 in |
| Width to Outside of Tracks | 52 in |
Undercarriage
| Number of Track Rollers per Side | 3 |
|---|
Fluid Capacities
| Fuel Tank | 5.3 gal |
|---|---|
| Hydraulic Tank | 6.1 gal |
| Engine oil w/ filter change | 1.0 gal |
| Radiator | 1.0 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 88 in |
|---|---|
| Max Reach Along Ground | 150 in |
| Max Vertical Wall Digging Depth | 53 in |
| Max Loading Height | 102 in |
| Shipping Length of Unit | 138 in |
| Max Cutting Height | 142 in |
| Shipping Height of Unit | 93 in |
| Max.Dumping Height | 102 in |
General Specifications
| Operating Weight lbs (kg) | 3,910 (1,775) — Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 7.8 (2.3) — Starting 2025 Model Year |
| Engine hp (kW) | 16.8 (12.5) — Starting 2025 Model Year |
| Digging Reach ft. (m) | 12.9 (3.9) — Starting 2025 Model Year |
Boom
| Arm Length | 62 in |
|---|---|
| Boom Length | 41 in |
Drive System
| Gradeability | 30 ° |
|---|---|
| Ground pressure | 4 psi |
| Maximum traction force | 3,300 lb |
| Max drawbar pull | 3,125 lb |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Lift System
| Bucket Breakout Force | 3,485 lb |
|---|---|
| Lift over end Max. reach - lbs | 816 lb |
| Lift over side Max. reach | 397 lb |
Boom/Stick Excavator Option 2
| Max Digging Depth | 94 in |
|---|---|
| Max Cutting Height | 145 in |
| Max Loading Height | 106 in |
| Max Vertical Wall Digging Depth | 57 in |
| Max Reach Along Ground | 156 in |
| Shipping Height of Unit | 93 in |
| Shipping Length of Unit | 138 in |
| Max.Dumping Height | 106 in |
Electrical System
| Voltage | 12 V |
|---|---|
| Battery | 1 x 12 V x 45 Ah |
| Alternator | — |
