Case
Kato
HD400VII
Excavator
50 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 38,581 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 74.3 gal/min |
| Hydraulic System Fluid Capacity | 39.1 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 4.7 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | DD-4BG1TRA |
|---|---|
| Displacement | 264 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 106.0 hp |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 114 in |
| Length of Track on Ground | 133 in |
| Tail Swing Radius | 94 in |
| Width to Outside of Tracks | 110 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 88 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 2.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 241 in |
|---|---|
| Max Reach Along Ground | 353 in |
| Max Loading Height | 264 in |
| Max Vertical Wall Digging Depth | 204 in |
| Max Cutting Height | 367 in |
| Shipping Length of Unit | 331 in |
| Shipping Height of Unit | 115 in |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.29 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 253 in |
|---|---|
| Max Vertical Wall Digging Depth | 223 in |
| Max Cutting Height | 379 in |
| Max Loading Height | 275 in |
| Max Reach Along Ground | 367 in |
| Shipping Length of Unit | 332 in |
| Shipping Height of Unit | 122 in |
