Hitachi
Tata Hitachi
EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 23,400 lb |
|---|---|
| Fuel Capacity | 132.1 gal |
| Hydraulic Pump Flow Capacity | 118.4 gal/min |
| Hydraulic System Fluid Capacity | 74.0 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 6.9 gal |
| Swing Drive Fluid Capacity | 2.5 gal |
Engine
| Engine Model | AH-4HK1X |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 177.0 hp |
| Aspiration | Turbocharged intercooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 496 lb-ft |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 47 |
| Number of Carrier Rollers per Side | 2 |
Bucket
| Reference Bucket Capacity | 1.40 yd³ |
|---|
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
