Case
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 7.4 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 6.9 gal/min |
| Hydraulic System Fluid Capacity | 6.7 gal |
| Engine Oil Capacity | 1.5 gal |
| Cooling System Fluid Capacity | 1.1 gal |
Engine
| Engine Model | 3TNV82A-SYB |
|---|---|
| Displacement | 1,330 in³ |
| Net Power | 23.0 hp |
| Max Torque | 59 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 97 in |
| Length of Track on Ground | 59 in |
| Tail Swing Radius | 30 in |
| Width to Outside of Tracks | 55 in |
Undercarriage
| Track Gauge | 46 in |
|---|
Boom/Stick Excavator Option 1
| Max Digging Depth | 91 in |
|---|---|
| Max Reach Along Ground | 161 in |
| Max Vertical Wall Digging Depth | 71 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
