Case

CX40B

Mini Excavator

Max Digging Depth
134 in
Net Power
43.0 hp
All mini excavators
Case CX40B Mini Excavator
1 / 5
Image 1 of 5
Image: brokentractor.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity14.1 gal
Hydraulic Pump Flow Capacity15.1 gal/min
Hydraulic System Fluid Capacity16.7 gal
Engine Oil Capacity2.0 gal
Cooling System Fluid Capacity1.6 gal

Engine

Engine specifications
Engine Model4TNV88A-XYB
Displacement2,190 in³
Net Power43.0 hp
Max Torque103 lb-ft

Dimensions

Dimensions specifications
Ground Clearance25 in
Height - Top of Cab103 in
Length of Track on Ground72 in
Tail Swing Radius40 in
Width to Outside of Tracks78 in

Undercarriage

Undercarriage specifications
Track Gauge62 in
Max Travel Speed2.7 mph

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth134 in
Max Reach Along Ground217 in
Max Vertical Wall Digging Depth104 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm
