Case
Tata Hitachi
EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight | 17,468 lb |
|---|---|
| Fuel Capacity | 26.0 gal |
| Hydraulic Pump Flow Capacity | 36.0 gal/min |
| Hydraulic System Fluid Capacity | 26.0 gal |
| Hydraulic System Relief Valve Pressure | 4,264 psi |
| Engine Oil Capacity | 2.4 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Operating Voltage | 12 V |
| Swing Drive Fluid Capacity | 0.6 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AU-4LE2X |
|---|---|
| Displacement | 133 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 54.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 155 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 107 in |
| Tail Swing Radius | 49 in |
| Width to Outside of Tracks | 91 in |
| Removal Counterweight Clearance | 30 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 18 in |
| Number of Shoes per Side | 39 |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 13,331 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 163 in |
|---|---|
| Max Reach Along Ground | 252 in |
| Max Loading Height | 207 in |
| Max Vertical Wall Digging Depth | 144 in |
| Max Cutting Height | 289 in |
| Shipping Length of Unit | 234 in |
| Shipping Height of Unit | 107 in |
Bucket
| Maximum Bucket Capacity | 0.99 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 180 in |
|---|---|
| Max Vertical Wall Digging Depth | 162 in |
| Max Cutting Height | 300 in |
| Max Loading Height | 219 in |
| Max Reach Along Ground | 268 in |
| Shipping Length of Unit | 234 in |
| Shipping Height of Unit | 117 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 166 in |
|---|---|
| Max Cutting Height | 283 in |
| Max Loading Height | 204 in |
| Max Vertical Wall Digging Depth | 128 in |
| Max Reach Along Ground | 251 in |
| Shipping Length of Unit | 235 in |
| Shipping Height of Unit | 118 in |
