John Deere
Tata Hitachi
EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 15,706 lb |
|---|---|
| Fuel Capacity | 35.7 gal |
| Hydraulic Pump Flow Capacity | 4.5 gal/min |
| Hydraulic System Fluid Capacity | 16.0 gal |
| Hydraulic System Relief Valve Pressure | 2,000 psi |
| Engine Oil Capacity | 2.3 gal |
| Cooling System Fluid Capacity | 1.6 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.4 gal |
Engine
| Engine Model | 4TNE98-JCF |
|---|---|
| Displacement | 202 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 55.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 165 lb-ft |
Dimensions
| Width to Outside of Tracks | 94 in |
|---|
Boom/Stick Excavator Option 1
| Shipping Length of Unit | 241 in |
|---|---|
| Shipping Height of Unit | 114 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
