Specifications
27 data points
Operating Specifications
| Operating Weight | 16,204 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 19.6 gal/min |
| Hydraulic System Relief Valve Pressure | 4,264 psi |
| Operating Voltage | 24 V |
Engine
| Engine Model | Isuzu 4LE2X |
|---|---|
| Power Measured @ | 2,000 rpm |
| Net Power | 55.2 hp |
| Stroke | 4 in |
| Bore | 3 in |
| Fuel | Requires ultra low-sulfur fuel B5 biodiesel tolerant |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 109 in |
| Tail Swing Radius | 52 in |
| Width to Outside of Tracks | 93 in |
| Overall Height | 109 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|
Fluid Capacities
| Fuel Tank | 32.0 gal |
|---|---|
| Hydraulic system | 25.0 gal |
| Engine Oil | 3.0 gal |
| Cooling system | 3.3 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 163 in |
|---|---|
| Max Reach Along Ground | 247 in |
General Specifications
| Operating Weight lbs (kg) | 17,400 (7,900) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 15.2 (4.6) Starting 2025 Model Year |
| Digging Reach ft. (m) | 22.2 (6.8) Starting 2025 Model Year |
| Engine hp (kW) | 53.6 (40) Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
