Case
Caterpillar
CB114
Smooth Drum Roller
22 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 5,510 lb |
|---|---|
| Max Speed | 8.5 mph |
| Fuel Capacity | 15.9 gal |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 10.0 gal |
| Engine Oil Capacity | 1.7 gal |
Engine
| Engine Model | D2011 L2 Tier III certified |
|---|---|
| Net Power | 31.0 hp |
| Make | Deutz |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 106 in |
| Wheelbase | 6 in |
| Overall Length | 9 in |
| Overall Width | 43 in |
| Turning Radius - Inside | 97 in |
| Drum Diameter - Front | 30 in |
| Drum Diameter - Rear | 30 in |
Drum
| Drum Width | 39 in |
|---|---|
| Drum Diameter | 29 in |
| Vibration Frequency 1 | 53 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 6,277 lb |
| Vibration Frequency 2 | 62 vpm |
| Static Linear Load | 6 lb-ft |
| Centrifugal Force - Low | 4,580 lb |
| Nominal Amplitude - Low | 0 in |
| Frequency | 3,180 – 3,720 vpm |
