Case
Thomas
1300
Skid Steer Loader
20 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 8,000 lb |
|---|---|
| Max Speed | 11.9 mph |
| Fuel Capacity | 25.5 gal |
| Hydraulic System Fluid Capacity | 6.1 gal |
| Tire Size | 12 x 16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 A |
| Engine Oil Fluid Capacity | 2.7 gal |
| Chain Box Fluid Capacity - each side | 2.0 gal |
| Operating Speed | 7.2 mph |
Engine
| Engine Model | 432T/M3 |
|---|---|
| Displacement | 195 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 76.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 225 lb-ft |
Hydraulic System
| Pump Flow Capacity | 12.2 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 79 in |
| Wheelbase | 52 in |
| Width Over Tires | 67 in |
| Reach at Max Lift and Dump | 29 in |
| Length with Bucket | 143 in |
| Clearance at Max Lift and Dump | 103 in |
| Turning Radius from Center - inc bucket | 84 in |
| Turning Radius from Center - machine rear | 70 in |
| Length w/o Bucket | 119 in |
Loader
| Bucket Capacity | 0.71 yd³ |
|---|---|
| Operating Load Rating | 2,500 lb |
| Tipping Angle | 5,000 ° |
| Operating Width | 70 in |
| Bucket Width | 72 in |
