Thomas
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 4,800 lb |
|---|---|
| Hydraulic System Fluid Capacity | 8.1 gal |
| Operating Speed | 6.3 mph |
Engine
| Engine Model | V1903E |
|---|---|
| Displacement | 113 in³ |
| Gross Power | 43.0 hp |
Hydraulic System
| Pump Flow Capacity | 14.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,400 psi |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 74 in |
| Wheelbase | 36 in |
| Width Over Tires | 54 in |
| Reach at Max Lift and Dump | 22 in |
| Length with Bucket | 127 in |
| Clearance at Max Lift and Dump | 90 in |
| Turning Radius from Center - inc bucket | 35 in |
| Turning Radius from Center - machine rear | 31 in |
| Length w/o Bucket | 103 in |
Loader
| Operating Load Rating | 1,300 lb |
|---|---|
| Breakout Force | 3,260 psi |
