Case
New Holland
LS160
Skid Steer Loader
30 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 8,090 lb |
|---|---|
| Max Speed | 7.0 mph |
| Fuel Capacity | 25.5 gal |
| Hydraulic System Fluid Capacity | 6.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 120 A |
| Engine Oil Fluid Capacity | 2.3 gal |
| Shipping Weight - Empty | 7,665 lb |
Engine
| Engine Model | F5H FL463 A*F001 |
|---|---|
| Displacement | 29 in³ |
| Power Measured @ | 2,500 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 232 lb-ft |
| Bore | 4 in |
| Stroke | 4 in |
| Starter | 4.3 hp |
Hydraulic System
| Displacement-Standard aux | 2 in³ |
|---|---|
| Displacement-High-flow aux | 1 in³ |
| Dump Time | 3.5 s |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 161 in |
| Wheelbase | 53 in |
| Width Over Tires | 71 in |
| Reach at Max Lift and Dump | 29 in |
| Height - Top of ROPS/FOPS | 79 in |
| Length with Bucket | 143 in |
| Length w/o Bucket | 119 in |
| Hinge pin height - fully raised | 130 in |
General Specifications
| Engine Power HP (KW) | 74 (55) Starting 2019 Model Year |
|---|---|
| Operating Width IN. (CM) | 69.6 (176.7) Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 2,800 (1,270) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 2,800 (1,270) Starting 2020 Model Year |
Loader
| Operating Load Rating | 2,800 lb |
|---|---|
| Operating Width | 70 in |
