Case
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 8,880 lb |
|---|---|
| Lift Configuration | Radial |
Engine
| Engine Model | FPT F5H FL463 A F001 |
|---|---|
| Displacement | 207 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 74.0 hp |
| Net Power | 68.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbo |
| Bore | 4 in |
| Stroke | 4 in |
| Alternator | 120 A |
| Emission Tier Level | Tier 4 |
| Battery | 12-volt low-maintenance |
| Peak Torque | 232 lb-ft |
| Fuel | 2 Diesel |
| Starter | 4.3 hp |
| Radiator Core type | All aluminum |
| Emissions compliance | Tier 4 Final Certified (CEGR DOC PM Catalyst) |
Weights
| Operating Weight | 8,878 lb |
|---|
Hydraulic System
| Pump Flow | 24.2 gal/min |
|---|---|
| Pump Type | Gear |
| Main Relief Pressure | 3,046 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 79 in |
| Width Over Tracks | 76 in |
| Height - Top of ROPS/FOPS | 79 in |
| Length with Bucket | 130 in |
| Track Width | 15,748 in |
| Height to Hinge Pin | 123 in |
| Overall Length with Foundry/ Excavating Bucket | 130 in |
| Dump Height with Foundry/ Excavating Bucket | 98 in |
Fluid Capacities
| Fuel Tank | 19.5 gal |
|---|---|
| Engine oil with filter | 2.3 gal |
Bucket
| Bucket Width | 73 in |
|---|
General Specifications
| Operating Width IN. (CM) | 74.3 (1.89) Starting 2019 Model Year |
|---|---|
| Engine Power HP (KW) | 74 (55) Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 2,170 (984) Starting 2019 Model Year |
| RATED OPERATING CAPACITY LBS. (35%) | 2,170 (984) Starting 2020 Model Year |
Loader
| Tipping Angle | 6,200 ° |
|---|---|
| Operating Load | 3,100 lb |
| Breakout Force | — |
| Operating Width | 74 in |
| High flow pump output | 32.4 gal/min |
| Standard hydraulic pump output | 24.2 gal/min |
| Rollback - Ground Level | 31 ° |
| Bucket Rollback at Max Height | 99 ° |
| Dump Clearance at Full Height Discharge | 99 in |
| Dump Reach | 26 in |
| Linkage Geometry | Radial |
| Straight Tipping Load | 6,195 lb |
| Loader | Joystick |
