Case
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 9,600 lb |
|---|---|
| Max Speed - high range | 8.3 mph |
| Max Speed - low range | 5.8 mph |
| Fuel Capacity | 25.5 gal |
| Hydraulic System Fluid Capacity | 11.8 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 A |
| Engine Oil Capacity | 2.6 gal |
Engine
| Engine Model | 432T/M3 |
|---|---|
| Displacement | 195 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 90.0 hp |
| Net Power | 84.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Peak Torque | 251 lb-ft |
Hydraulic System
| Pump Flow | 12.2 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of Cab | 79 in |
| Reach at Max Lift and Dump | 22 in |
| Width Over Tracks | 76 in |
| Length with Bucket | 143 in |
| Clearance at Max Lift and Dump | 103 in |
| Turning Radius from Center - inc bucket | 86 in |
| Turning Radius from Center - machine rear | 70 in |
| Length - without Bucket | 119 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Width of Track | 16 in |
| Ground Contact Area | 2,038 in³ |
| Track Gauge | 60 in |
Loader
| Bucket Capacity | 0.71 yd³ |
|---|---|
| Tipping Angle | 6,400 ° |
| Operating Load | 3,200 lb |
| Bucket Width | 78 in |
