Case
Tata Hitachi
EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 21,054 lb |
|---|---|
| Fuel Capacity | 33.9 gal |
| Hydraulic Pump Flow Capacity | 39.9 gal/min |
| Hydraulic System Fluid Capacity | 24.9 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Engine Oil Capacity | 3.5 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Tire Size | 500/45-20 |
Engine
| Engine Model | 439TC-M2 |
|---|---|
| Displacement | 238 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 99.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 88 in |
| Overall Width | 24 in |
| Overall Width - Outriggers Down | 107 in |
Transmission
| Max Travel Speed | 20.6 mph |
|---|---|
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 156 in |
|---|---|
| Max Reach Along Ground | 306 in |
| Shipping Length of Unit | 274 in |
| Shipping Height of Unit | 120 in |
| Max Vertical Wall Dig Depth | 85 in |
