Caterpillar
John Deere
770D
Motor Grader
66 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Std Operation Weight - Total | 25,320 lb |
|---|---|
| Tire Size | 13x24 8 PR |
| Fuel Capacity | 60.0 gal |
Engine
| Displacement | 427 in³ |
|---|---|
| Max Power | 125.0 hp |
| Net Power Gear 5-6 | 125.0 hp |
Dimensions
| Wheelbase | 224 in |
|---|---|
| Overall Length | 313 in |
| Width Over Tires | 96 in |
| Height to Top of Isomount Cab | 132 in |
| Blade Base | 98 in |
Transmission
| Max Speed - Forward | 25.5 mph |
|---|---|
| Max Speed - Reverse | 25.5 mph |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 6 |
Circle
| Max Lift Above Ground | 16 in |
|---|
Steering System
| Turning Radius | 264 in |
|---|
