8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
69 data points
Engine
| Engine Model | Cat C2.4 |
|---|---|
| Displacement | 146 in³ |
| Net Power | 40.2 hp |
| Bore | 3 in |
| Stroke | 4 in |
| Emissions | Meets U.S. EPA Tier 4 Final/EU Stage IIIA emission standards. |
Hydraulic System
| Operating Pressure - Equipment | 3,553 psi |
|---|---|
| Operating Pressure - Swing | 3,132 psi |
| Operating Pressure - Travel | 3,553 psi |
| Digging Force - Bucket | 10,050 lb |
| Digging Force - Stick - Standard | 5,550 lb |
| Digging Force - Stick - Long | 4,788 lb |
| Hydraulic System Type | Load Sensing Hydraulics with Variable Displacement Piston Pump |
| Pump Flow at 2,400 rpm | 39.6 gal/min |
Boom/Stick Excavator Option 1
| Max Digging Depth | 130 in |
|---|---|
| Max Reach Along Ground | 210 in |
General Specifications
| Net Power | 40.20 hp (29.98 kw) Starting 2021 Model Year |
|---|---|
| Operating Weight | 9,330.00 lbs (4,232.02 kg) Starting 2021 Model Year |
| Max Digging Depth | 77.00 ft (23.47 m) Starting 2021 Model Year |
| Engine | C2.4 Starting 2021 Model Year |
Service Refill Capacities
| Engine Oil | 2.5 gal |
|---|---|
| Hydraulic Tank | 18.0 gal |
| Fuel Tank | 16.6 gal |
| Hydraulic System | 20.6 gal |
| Cooling System | 2.8 gal |
Blades
| Blade Width | 78 in |
|---|---|
| Blade Height | 15 in |
| Blade Lift Height | 16 in |
| Dig Depth | 22 in |
Swing System
| Machine Swing Speed | 10 rpm |
|---|---|
| Boom Swing - Left - Without Stop | 80 ° |
| Boom Swing - Left - With Stop | 60 ° |
Travel System
| Travel Speed - High | 2.7 mph |
|---|---|
| Travel Speed - Low | 1.7 mph |
| Maximum Traction Force - High Speed | 5,418 lb |
| Maximum Traction Force - Low Speed | 10,161 lb |
| Gradeability - Maximum | 30 ° |
Dimensions - Long Stick
| Boom In Reach | 100 in |
|---|---|
| Dig Depth | 144 in |
| Maximum Blade Depth | 22 in |
| Maximum Blade Height | 16 in |
| Maximum Dig Height | 214 in |
| Maximum Dump Clearance | 154 in |
| Maximum Reach | 235 in |
| Maximum Reach - Ground Level | 229 in |
| O/A Undercarriage Length | 102 in |
| Swing Bearing - Height | 24 in |
| Track Belt/Shoe Width | 16 in |
| Vertical Wall | 104 in |
| Boom Swing - Left | 27 in |
| Boom Swing - Right | 31 in |
| O/A Shipping Length | 208 in |
| O/A Track Width | 78 in |
Dimensions - Standard Stick
| Boom In Reach | 93 in |
|---|---|
| Dig Depth | 129 in |
| Maximum Blade Depth | 22 in |
| Maximum Blade Height | 16 in |
| Maximum Dig Height | 207 in |
| Maximum Dump Clearance | 129 in |
| Maximum Reach | 220 in |
| Maximum Reach - Ground Level | 210 in |
| O/A Undercarriage Length | 102 in |
| Swing Bearing - Height | 24 in |
| Track Belt/Shoe Width | 16 in |
| Vertical Wall | 91 in |
| Boom Swing - Left | 27 in |
| Boom Swing - Right | 31 in |
| O/A Shipping Length | 204 in |
| O/A Track Width | 78 in |
