8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Fuel Capacity | 30.4 gal |
|---|---|
| Hydraulic System Fluid Capacity | 24.3 gal |
| Hydraulic System Relief Valve Pressure | 3,980 psi |
| Alternator Supplied Amperage | 35 A |
| Engine Oil Capacity | 2.6 gal |
| Cooling System Fluid Capacity | 4.0 gal |
Engine
| Engine Model | C 4M40E1 |
|---|---|
| Displacement | 173 in³ |
| Gross Power | 55.0 hp |
| Net Power | 54.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 103 in |
| Tail Swing Radius | 52 in |
| Width to Outside of Tracks | 91 in |
| Digging Depth | 180 in |
| Digging Reach | 180 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 74 in |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 18 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 163 in |
|---|---|
| Max Reach Along Ground | 246 in |
| Max Vertical Wall Digging Depth | 133 in |
| Max Loading Height | 207 in |
| Shipping Length of Unit | 230 in |
| Max Cutting Height | 292 in |
| Shipping Height of Unit | 103 in |
Bucket
| Reference Bucket Capacity | 0.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.50 yd³ |
| Minimum Bucket Capacity | 0.20 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|---|
| Swing Torque | 11,801 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 186 in |
|---|---|
| Max Cutting Height | 307 in |
| Max Loading Height | 223 in |
| Max Vertical Wall Digging Depth | 162 in |
| Max Reach Along Ground | 268 in |
| Shipping Height of Unit | 108 in |
| Shipping Length of Unit | 230 in |
