CaterpillarCaterpillar
305.5E CR
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 18,519 lb |
|---|---|
| Fuel Capacity | 33.0 gal |
| Hydraulic System Fluid Capacity | 21.7 gal |
| Engine Oil Capacity | 3.0 gal |
| Cooling System Fluid Capacity | 3.7 gal |
Engine
| Engine Model | Cat C3.3B |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 66.6 hp |
| Net Power | 65.0 hp |
| Aspiration | Turbocharged |
| Engine Make | Caterpillar |
| Bore | 4 in |
| Stroke | 5 in |
| Net Power - ISO 9249 | 65.0 hp |
| Emissions | Meets U.S. EPA Tier 4 Final and EU Stage IIIB emission standards. |
Weights
| Operating Weight | 18,519 lb |
|---|
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 79 in |
| Max Travel Speed | 3.5 mph |
| Drawbar Pull | 20,720 lb |
Bucket
| Maximum Bucket Capacity | 1.10 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.50 yd³ |
Service Refill Capacities
| Engine Oil | 3.0 gal |
|---|---|
| Hydraulic Tank | 21.7 gal |
| Fuel Tank | 33.0 gal |
| Cooling System | 3.7 gal |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
