Caterpillar
Takeuchi
TB175W
Mini Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
72 data points
Engine
| Engine Model | Cat C3.3B |
|---|---|
| Displacement | 203 in³ |
| Net Power | 70.3 hp |
| Bore | 4 in |
| Stroke | 5 in |
Weights
| Operating Weight | 20,731 lb |
|---|
Hydraulic System
| Operating Pressure - Equipment | 4,134 psi |
|---|---|
| Operating Pressure - Swing | 3,626 psi |
| Operating Pressure - Travel | 4,134 psi |
| Digging Force - Bucket | 13,943 lb |
| Digging Force - Stick - Standard | 9,500 lb |
| Digging Force - Stick - Long | 8,023 lb |
| Hydraulic System Type | Load Sensing Hydraulics with Variable Displacement Piston Pump |
| Pump Flow at 2,400 rpm | 62.0 gal/min |
| Auxiliary Circuit - Secondary - Flow | 9.0 gal/min |
| Auxiliary Circuit - Secondary - Pressure | 4,134 psi |
General Specifications
| Net Power | 69.50 hp (51.83 kw) — Starting 2023 Model Year |
|---|---|
| Operating Weight lbs (kg) | 20,731 (9,403.4) — Starting 2025 Model Year |
| Operating Weight | 21,091.00 lbs (9,566.73 kg) — Starting 2021 Model Year |
| Max Digging Depth | 182.8 in ft (55.72 m) — Starting 2023 Model Year |
| Digging Depth ft (m) | 15.3 (4.7) — Starting 2025 Model Year |
| Engine hp (kW) | 70.3 (52.4) — Starting 2025 Model Year |
| Digging Reach ft. (m) | 25.1 (7.7) — Starting 2025 Model Year |
| Engine | C3.3B — Starting 2021 Model Year |
Service Refill Capacities
| Engine Oil | 3.0 gal |
|---|---|
| Hydraulic Tank | 14.0 gal |
| Fuel Tank | 39.0 gal |
| Hydraulic System | 28.0 gal |
| Cooling System | 2.6 gal |
Blades
| Blade Height | 17 in |
|---|
Swing System
| Machine Swing Speed | 11 rpm |
|---|
Travel System
| Travel Speed - High | 3.1 mph |
|---|---|
| Travel Speed - Low | 1.6 mph |
| Maximum Traction Force - High Speed | 6,497 lb |
| Maximum Traction Force - Low Speed | 19,064 lb |
| Gradeability - Maximum | 30 ° |
| Ground Pressure - Maximum Weight | 6 psi |
| Ground Pressure - Minimum Weight | 6 psi |
Dimensions - Long Stick
| Boom In Reach | 127 in |
|---|---|
| Dig Depth | 183 in |
| Maximum Blade Depth | 27 in |
| Maximum Blade Height | 14 in |
| Maximum Dig Height | 277 in |
| Maximum Dump Clearance | 199 in |
| Maximum Reach | 301 in |
| Maximum Reach - Ground Level | 294 in |
| O/A Undercarriage Length | 126 in |
| Swing Bearing - Height | 29 in |
| Track Belt/Shoe Width | 18 in |
| Vertical Wall | 134 in |
| Boom Swing - Left | 24 in |
| Boom Swing - Right | 37 in |
| O/A Shipping Length | 262 in |
| O/A Track Width | 97 in |
| Stick Length | 93 in |
Dimensions - Standard Stick
| Boom In Reach | 120 in |
|---|---|
| Dig Depth | 162 in |
| Maximum Blade Depth | 27 in |
| Maximum Blade Height | 14 in |
| Maximum Dig Height | 265 in |
| Maximum Dump Clearance | 187 in |
| Maximum Reach | 281 in |
| Maximum Reach - Ground Level | 274 in |
| O/A Undercarriage Length | 126 in |
| Swing Bearing - Height | 29 in |
| Track Belt/Shoe Width | 18 in |
| Vertical Wall | 118 in |
| Boom Swing - Left | 24 in |
| Boom Swing - Right | 37 in |
| O/A Shipping Length | 259 in |
| O/A Track Width | 97 in |
| Stick Length | 72 in |
