Specifications
47 data points
Operating Specifications
| Operating Weight | 29,770 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic System Fluid Capacity | 43.4 gal |
| Engine Oil Capacity | 3.6 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Swing Drive Fluid Capacity | 0.7 gal |
Engine
| Engine Model | Cat C4.4 ACERT |
|---|---|
| Displacement | 269 in³ |
| Gross Power | 95.0 hp |
| Net Power | 91.0 hp |
| Bore | 4 in |
| Stroke | 5 in |
| Gross Power - SAE J1995 | 95.0 hp |
| Net Power - SAE J1349 | 91.0 hp |
| Flywheel Power | 91.0 hp |
Weights
| Operating Weight | 33,080 lb |
|---|---|
| Maximum Operating Weight | 33,080 lb |
| Minimum Operating Weight | 29,770 lb |
Hydraulic System
| Maximum Pressure - Swing | 3,336 psi |
|---|---|
| Maximum Pressure - Travel | 5,076 psi |
| Boom Cylinder - Bore | 4 in |
| Boom Cylinder - Stroke | 40 in |
| Stick Cylinder - Bore | 5 in |
| Stick Cylinder - Stroke | 47 in |
| Maximum Pressure - Equipment | 4,424 psi |
| Swing System - Maximum Flow | 34.0 gal/min |
| Bucket Cylinder - Bore | 4 in |
| Bucket Cylinder - Stroke | 37 in |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 109 in |
| Tail Swing Radius | 85 in |
| Removal Counterweight Clearance | 36 in |
Undercarriage
| Max Travel Speed | 3.4 mph |
|---|---|
| Drawbar Pull | 25,628 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 238 in |
|---|---|
| Max Reach Along Ground | 340 in |
Drive System
| Maximum Drawbar Pull | 25,628 lb |
|---|
Service Refill Capacities
| Cooling System | 5.9 gal |
|---|---|
| Hydraulic System - Including Tank | 43.4 gal |
| Final Drive - Each | 0.8 gal |
| Hydraulic Tank | 24.0 gal |
| Fuel Tank Capacity | 66.1 gal |
| Swing Drive | 0.7 gal |
Standards
| Brakes | ISO 10265 2008 |
|---|
Track
| Number of Shoes - Each Side - Long Undercarriage | — |
|---|---|
| Number of Track Rollers - Each Side - Long Undercarriage | — |
| Number of Carrier Rollers - Each Side - Long Undercarriage | — |
