Caterpillar
323D L
- Operating Weight
- 48,193 lb
- Max Digging Depth
- 228 in
- Max Digging Depth
- 245 in
- Net Power
- 140.0 hp
.jpg)
1 / 5
Image 1 of 5
Specifications
77 data points
Operating Specifications
| Operating Weight | 48,193 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Hydraulic Pump Flow Capacity | 108.4 gal/min |
| Hydraulic System Fluid Capacity | 68.7 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Engine Oil Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 6.7 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 2.2 gal |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | Cat C6.4 ACERT |
|---|---|
| Displacement | 389 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 140.0 hp |
| Aspiration | Turbocharged |
| Stroke | 5 in |
| Bore | 4 in |
| Net Power - ISO 9249 | 150.0 hp |
| Net Power - EEC 80/1269 | 150.0 hp |
Weights
| Operating Weight | 50,706 lb |
|---|
Hydraulic System
| Maximum Pressure - Swing | 3,626 psi |
|---|---|
| Maximum Pressure - Travel | 5,076 psi |
| Boom Cylinder - Bore | 5 in |
| Boom Cylinder - Stroke | 50 in |
| Main Implement System - Maximum Flow (2x) | 54.0 gal/min |
| Stick Cylinder - Bore | 6 in |
| Stick Cylinder - Stroke | 59 in |
| Maximum Pressure - Equipment | 5,076 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 109 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 41 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 95 in |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Drawbar Pull | 46,311 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 228 in |
|---|---|
| Max Reach Along Ground | 354 in |
| Max Loading Height | 236 in |
| Max Vertical Wall Digging Depth | 148 in |
| Max Cutting Height | 353 in |
| Shipping Length of Unit | 383 in |
| Shipping Height of Unit | 122 in |
Bucket
| Reference Bucket Capacity | 1.50 yd³ |
|---|
Drive System
| Maximum Drawbar Pull | 46,310 lb |
|---|
Service Refill Capacities
| Cooling System | 6.6 gal |
|---|---|
| Hydraulic System - Including Tank | 69.0 gal |
| Final Drive - Each | 2.6 gal |
| Engine Oil | 8.0 gal |
| Hydraulic Tank | 32.0 gal |
| Fuel Tank Capacity | 108.0 gal |
| Swing Drive | 2.1 gal |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 245 in |
|---|---|
| Max Vertical Wall Digging Depth | 200 in |
| Max Cutting Height | 370 in |
| Max Loading Height | 260 in |
| Max Reach Along Ground | 372 in |
| Shipping Length of Unit | 373 in |
| Shipping Height of Unit | 121 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 263 in |
|---|---|
| Max Cutting Height | 378 in |
| Max Loading Height | 268 in |
| Max Vertical Wall Digging Depth | 219 in |
| Max Reach Along Ground | 389 in |
| Shipping Length of Unit | 373 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 210 in |
|---|---|
| Max Cutting Height | 343 in |
| Max Reach Along Ground | 336 in |
| Max Loading Height | 226 in |
| Max Vertical Wall Dig Depth | 142 in |
| Shipping Length of Unit | 365 in |
Standards
| Brakes | SAE J1026 APR90 |
|---|---|
| Cab/FOGS | SAE J1356 FEB88 |
