420

Specifications

18 data points

General Specifications specifications
Operating Weight lbs (kg)	16,279 (7384) - 24,251 (11,000) — Starting 2024 Model Year
Operating Weight (Maximum)	24,251.00 lbs (11,000.08 kg) — Starting 2023 Model Year
Bucket Capacity (General Purpose)	1.31 cu yd — Starting 2021 Model Year
Max Digging Depth ft. (m)	14.2 (4.3) — Starting 2024 Model Year
Lift Capacity at Full Height	7,245.00 lbs (3,286.28 kg) — Starting 2023 Model Year
Backhoe Loading Height ft. (m)	12 (3.7) - 13.9 (4.2) — Starting 2024 Model Year
Travel Speed 4th Gear Fwd MPH (kmh)	25 (40) — Starting 2024 Model Year
Loader SAE HP (kw)	92 (68) — Starting 2024 Model Year
Loader Lift Capacity lbs. (kg)	7,230 (3,280) — Starting 2024 Model Year
Loader Breakout Force lbs. (kg)	12,643 (5734) — Starting 2024 Model Year
Engine	C3.6 — Starting 2023 Model Year
Bucket Dig Force (Standard)	14,431.00 lbs ft (19,565.55 nm) — Starting 2021 Model Year
Digging Depth (Extendable Stick)	17.90 ft (5.46 m) — Starting 2021 Model Year
Digging Depth (Standard Stick)	14.00 ft (4.27 m) — Starting 2021 Model Year
Dump Height Max Angle	9.20 ft (2.80 m) — Starting 2023 Model Year
Loading Height (Standard)	12.20 ft (3.72 m) — Starting 2023 Model Year
Net	92 — Starting 2021 Model Year
Stick Dig Force (Standard)	9,786.00 lbs ft (13,267.86 nm) — Starting 2023 Model Year
