CaterpillarCaterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
62 data points
Operating Specifications
| Operating Weight 4wd | 16,116 lb |
|---|---|
| Fuel Capacity | 38.0 gal |
| Hydraulic System Fluid Capacity | 20.9 gal |
| Cooling System Fluid Capacity | 4.4 gal |
| Tire Size Front - 2wd / 4wd | 11L-16 F-3/12.5/80-18 (10ply) 1-3 Super Traction |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.0 gal |
| Turning Radius | 214 in |
| Transmission Fluid Capacity | 5.0 gal |
| Max Weight | 24,251 lb |
| Rear Axle Fluid Capacity | 4.4 gal |
| Front Axle Fluid Capacity | 2.9 gal |
Engine
| Engine Model | C4.4 DIT |
|---|---|
| Displacement | 268 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 101.0 hp |
| Net Power | 93.0 hp |
| Torque Measured @ | 1,400 rpm |
| Net Max Torque | 301 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 43.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,611 psi |
| Pump Type | variable-flow axial piston |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 88 in |
| Transport Width | 96 in |
| Transport Length | 289 in |
| Height to Top of Suspended Cab | 111 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Tires & Wheels
| Rear Tires Size | 19.5L-24 (12 ply) R4 ATU/ 19.5L-24 (12 ply) IT 525 |
|---|
General Specifications
| Operating Weight lbs (kg) | 23,568 (10,690) Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.3 (4.4) Starting 2011 Model Year |
| Lift Capacity lbs (kgs) | 6,340 (2,876) Starting 2007 Model Year |
| Loading Height ft (m) | 13.6 (4.1) Starting 2007 Model Year |
| 4th Gear Fwd mph (kmh) | 25 (40) Starting 2010 Model Year |
| Backhoe Loading Height ft. (m) | 11.9 (3.6) Starting 2011 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 25 (40.0) Starting 2011 Model Year |
| Breakout Force lbs (kgs) | 10,076 (4,570) Starting 2007 Model Year |
| Digging Depth ft (m) | 17.9 (5.5) Starting 2008 Model Year |
| Loader SAE HP (kw) | 93 (69.3) Starting 2011 Model Year |
| Loader Lift Capacity lbs. (kg) | 6,340 (2,876) Starting 2011 Model Year |
| Loader Breakout Force lbs. (kg) | 10,076 (4,570) Starting 2011 Model Year |
| SAE Net hp (kW) | 89 (66) Starting 2006 Model Year |
| SAE HP (KW) | 101 (75) Starting 2010 Model Year |
| Weight lbs (kg) | 15,474 (7,025) Starting 2010 Model Year |
Backhoe
| Dig Depth | 173 in |
|---|---|
| Reach From Swivel | 222 in |
| Dig Depth - Extended | 216 in |
| Load Height - Extended | 163 in |
| Bucket Dig Force | 13,875 lb |
| Reach From Swivel - Extended | 263 in |
| Reach at Load Height - Extended | 109 in |
| Bucket Dig Force - Extended | 13,863 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 102 in |
| Bucket Breakout Force | 10,242 lb |
| Bucket Width | 8 in |
| Reach at Max Dump Height | 35 in |
| Dig Depth | 4 in |
