CaterpillarCaterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight 4wd | 24,251 lb |
|---|---|
| Operating Weight 2wd | 15,395 lb |
| Fuel Capacity | 44.0 gal |
| Hydraulic System Fluid Capacity | 25.1 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Oil System Fluid Capacity | 2.3 gal |
| Transmission Fluid Capacity | 4.9 gal |
| Rear Axle Fluid Capacity | 4.4 gal |
| Front Axle Fluid Capacity | 3.0 gal |
Engine
| Engine Model | C4.4 ACERT |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 102.0 hp |
| Net Power | 102.0 hp |
| Number of Cylinders | 1,400 |
| Net Max Torque | 323 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 43.1 gal/min |
|---|---|
| Pump Type | Variable Flow Axial Piston |
Dimensions
| Wheelbase | 88 in |
|---|---|
| Transport Width | 93 in |
| Transport Length | 285 in |
| Height to Top of Suspended Cab | 111 in |
Transmission
| Max Speed | 25.0 mph |
|---|
General Specifications
| Operating Weight lbs (kg) | 15,829 (7,180) — Starting 2013 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.3 (4.4) — Starting 2013 Model Year |
| Backhoe Loading Height ft. (m) | 11.9 (3.6) — Starting 2013 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 25 (40) — Starting 2013 Model Year |
| Loader SAE HP (kw) | 93 (69.3) — Starting 2013 Model Year |
| Loader Lift Capacity lbs. (kg) | 8,137 (3,691) — Starting 2013 Model Year |
| Loader Breakout Force lbs. (kg) | 11,575 (5,250) — Starting 2013 Model Year |
Backhoe
| Dig Depth | 173 in |
|---|---|
| Dig Depth - Extended | 215 in |
| Load Height | 143 in |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Lift Capacity | 8,137 lb |
| Bucket Breakout Force | 11,197 lb |
| Bucket Width | 89 in |
| Reach at Max Dump Height | 32 in |
| Dig Depth | 3 in |
