CaterpillarCaterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight 4wd | 14,888 lb |
|---|---|
| Operating Weight 2wd | 14,623 lb |
| Fuel Capacity | 28.1 gal |
| Hydraulic System Fluid Capacity | 21.7 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Tire Size Front - 2wd / 4wd | 11L-16 12PR/10.5-20 10PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 1.9 gal |
| Alternator Supplied Amperage | 52 A |
| Turning Radius | 155 in |
| Transmission Fluid Capacity | 2.7 gal |
| Rear Axle Fluid Capacity | 4.9 gal |
| Front Axle Fluid Capacity | 2.0 gal |
Engine
| Engine Model | 4.236 |
|---|---|
| Displacement | 236 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 75.0 hp |
| Net Power | 70.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 36.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,700 psi |
| Pump Type | Variable |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 90 in |
| Transport Length | 272 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 19.6 mph |
|---|---|
| Max Speed - Reverse | 19.7 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Fully synchromesh |
Tires & Wheels
| Rear Tires Size | 16.9-24 8PR / 19.5L-24 8PR |
|---|
Backhoe
| Dig Depth | 185 in |
|---|---|
| Reach From Swivel | 228 in |
| Dig Depth - Extended | 236 in |
| Load Height - Extended | 172 in |
| Bucket Dig Force | 10,440 lb |
| Reach From Swivel - Extended | 278 in |
| Reach at Load Height - Extended | 135 in |
| Bucket Dig Force - Extended | 10,260 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 102 in |
| Bucket Breakout Force | 7,666 lb |
| Bucket Width | 89 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 4 in |
