CaterpillarCaterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Fuel Capacity | 33.9 gal |
|---|---|
| Hydraulic System Fluid Capacity | 20.9 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Tire Size Front - 2wd / 4wd | 11L-16 /10.5-20 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.2 gal |
| Alternator Supplied Amperage | 52 A |
| Transmission Fluid Capacity | 2.7 gal |
| Max Weight | 14,969 lb |
| Rear Axle Fluid Capacity | 4.9 gal |
Engine
| Engine Model | 3054 |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 61.1 hp |
| Net Power | 58.9 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Make | Caterpillar |
| Bore | 4 in |
| Stroke | 5 in |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 10.9 gal/min |
|---|---|
| Relief Valve Pressure | 4,013 psi |
| Pump Type | Closed-center |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 81 in |
| Transport Width | 90 in |
| Transport Length | 272 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 20.1 mph |
|---|---|
| Max Speed - Reverse | 20.2 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Power shuttle - full synchro |
Tires & Wheels
| Rear Tires Size | 16.9-24 / 19.5L-24 |
|---|
Backhoe
| Dig Depth | 186 in |
|---|---|
| Reach From Swivel | 239 in |
| Dig Depth - Extended | 244 in |
| Load Height - Extended | 194 in |
| Bucket Dig Force | 14,440 lb |
| Reach From Swivel - Extended | 292 in |
| Reach at Load Height - Extended | 108 in |
| Bucket Dig Force - Extended | 14,440 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 103 in |
| Bucket Breakout Force | 9,217 lb |
| Bucket Width | 89 in |
| Reach at Max Dump Height | 32 in |
| Dig Depth | 4 in |
