CaterpillarCaterpillar
434E
Backhoe Loader
37 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight 4wd | 17,059 lb |
|---|---|
| Fuel Capacity | 33.9 gal |
| Tire Size Front - 2wd / 4wd | 12.5/80x1810PR |
| Turning Radius | 211 in |
Engine
| Engine Model | 3054T |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 83.0 hp |
| Net Power | 80.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 43.1 gal/min |
|---|---|
| Relief Valve Pressure | 3,307 psi |
| Pump Type | LSPC closed center |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 95 in |
| Transport Length | 227 in |
| Height to Top of Suspended Cab | 115 in |
Transmission
| Max Speed | 19.8 mph |
|---|---|
| Max Speed - Reverse | 19.8 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | power shuttle |
Tires & Wheels
| Rear Tires Size | 16.9x2810PR |
|---|
Backhoe
| Dig Depth | 192 in |
|---|---|
| Reach From Swivel | 222 in |
| Dig Depth - Extended | 233 in |
| Load Height - Extended | 169 in |
| Bucket Dig Force | 12,840 lb |
| Reach From Swivel - Extended | 263 in |
| Reach at Load Height - Extended | 109 in |
| Bucket Dig Force - Extended | 12,730 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 103 in |
| Bucket Breakout Force | 11,465 lb |
| Bucket Width | 89 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 3 in |
